Brilliance in Every Pixel!
The Innex CD Series delivers stunning 4K resolution, a 178° wide viewing angle, and versatile display options in sizes from 43″ to 86″. Perfect for meeting rooms, classrooms, and retail spaces, it offers 24/7 durability and both landscape and portrait modes. With cloud control, managing content and displays is simple, allowing seamless updates and synchronization from anywhere for enhanced efficiency.
Unmatched for Any Space!
Corporate Offices & Meeting Rooms
Educational Institutions
Retail & Public Spaces
A High Reliability Display
4K Quality
The CD Series offers exceptional 4K quality, ensuring that every image is presented with stunning clarity and precision. With 60Hz refresh rate and a 178° viewing angle, the display provides the best visual quality and readability for all types of content.
Non-stop Operation
Designed for 24/7 operation, the CD Series is built to handle continuous, high-demand environments. Its durability ensures reliable performance around the clock, ideal for businesses needing dependable digital displays.
Portrait & Landscape Flexibility
The CD Series offers versatile portrait and landscape flexibility, easily switching between orientations to fit any content or environment.
Wide Viewing Angle
The CD Series features a wide viewing angle of 178° , offering optimal usability, experience, and viewing comfort.
Easy & Secure Content Delivery
The Digital Signage Software makes content management easy and secure. With user-friendly configuration options, you can quickly set up a secure cloud server for sharing and controlling digital signage content. Authorized users can access displays remotely, ensuring that content updates are efficient and safe, no matter where you are.
SPECIFICATIONS
Display Dimension: 43”/55”/65″/75″/86″
Brightness: 500cd/m2 (TYP)
Contrast: 1200: 1 (IPS)/ 4000:1 (VA)
Dynamic Contrast: 5000:1
Anti-Glare: 25% Haze
Back-Light: DLED
Resolution: 3840×2160 (pixels, RGB)
Aspect Ratio: 16:9
Response Time:
CD43/ 8ms
CD55/ 8ms
CD65/ 6.5ms
CD75/ 8.5ms
CD86/ 8ms
Display Color: 1.07B (10bit)
Panel Frequency: 60 Hz
Life Time: 30,000 Hrs (min.)
In: DC x1, RJ45 x1, USB OTG x1, USB 3.0 x1, HDMI x1, TF card x1
Out: Line x1
USB type Wi-Fi module: IEEE 802.11a/b/g/n/ac Dual Band 2.4/5GHz
Ethernet Network: 10M/100M/1000M
Power Input: 100V~240V AC
Rated Power Consumption:
CD43/ Maximum ≤ 150W
CD55/ Maximum ≤ 180W
CD65/ Maximum ≤ 220W
CD75/ Maximum ≤ 280W
CD86/ Maximum ≤ 380W
Standby Power Consumption: ≤ 0.5W
Speaker Output: 10W x2
Operating Temperature: 0 ℃~ 45 ℃
Storage Temperature: -10 ℃~ 55 ℃
Operation Humidity: 20% ~ 80%RH
Storage Temperature: 20% ~ 90%RH
Operating System: Android 11
RAM: DDR4 2GB
Internal Storage: 32GB (EMMC )
CPU/ GPU : Cortex-A55*4
UI Resolution: 4K
Panel Dimension:
CD43/ 960*550*65mm
CD55/ 1230*700*65mm
CD65/ 1450*825*65mm
CD75/ 1670*950*65mm
CD86/ 1920*1090*65mm
Package Dimension:
CD43/ 1090*680*160mm
CD55/ 1360*840*160mm
CD65/ 1545*930*165mm
CD75/ 1830*1145*195mm
CD86/ 2080*1295*195mm
Net Weight:
CD43/ 9.75kg
CD55/ 15.2kg
CD65/ 22kg
CD75/ 28.5kg
CD86/ 37.5kg
Packed Weight:
CD43/ 14.5kg
CD55/ 19.2kg
CD65/ 27kg
CD75/ 39kg
CD86/ 49.5kg
VESA Mount Point:
CD43/ 400*400mm
CD55/ 400*400mm
CD65/ 400*400mm
CD75/ 600*400mm
CD86/ 800*600mm
Regulatory Certification: CE
1.5M HDMI Cable x1, 3M EU Power Cable x1, 3M UK Power Cable x1, Remote control x1, Warranty Card, Safety documents, Wi-Fi dongle x1, Wall bracket x1
